DW-60 mini excavator is suitable for agricultural planting, landscaping, orchard digging and fertilization, small earth and rock works, municipal works, road repair, basement and indoor construction,
Concrete crushing, buried cable, water pipeline laying, garden cultivation and river channel dredging projects and other working environments.
It has the functions of digging, crushing, clearing hook, drilling, dodging, can quickly replace the accessories, the machine utilization rate is greatly improved, can be applied to all kinds of soil, good use effect, simple operation,Small and flexible, easy to transport, can work in a small site.
Technical parameter |
Safety and protection equipment |
Left and right mirrors
| Front working light |
Chassis system and shield |
Track tensioning mechanism
| Bottom frame traction ring |
400 mm three-rib track plate
| Chassis bottom sealing plate |
Walking motor seal plate
| Track clamp |
Dozer blade | Support sprocket and support wheel |
Working device |
Swing arm ● Bucket rod |
Bucket 0.23m³ |
Electronic system |
Battery(1x90Ah) | ● 12V Power interface |
Engine cooling water temperature display | Oil level indication |
Engine speed indication | Working hour meter |
Oil pressure, engine overheating alarm
| Charge indication
|
Air filter blocked alarm | Engine warm-up indication
|
Hydraulic oil temperature alarm |
|
Engine |
Model number | 4TNV94L-BVXG |
|
Direct injection | / | √ |
Four-stroke | / | √ |
Water-cooling | / | √ |
Turbocharging | / | × |
Air-to-air intercooler | / | √ |
Number of cylinders | / | √ |
Rated power | 36.2/2200 | kw/rpm |
Maximum torque/speed | 207.4/1000 | N.m/rpm |
Displacement | 3.054 | L |
Lifting capacity
Height of the lifting point (m) | Nominal lifting capacity - forward (backwards) (kg) | Nominal lifting capacity (on the side) (kg) |
Radius of the point Elevation (m) | Capacity of Lifting in the radius maximum | Radius of the lifting point (m) | Capacity of Lifting in the radius maximum |
| 1.5 | 3 |
| 1.5 | 1.5 | 1.8 |
4.5 |
|
|
| *990 |
|
|
| 870 |
3 |
|
| 870 | 750 |
|
| 630 | 530 |
1.5 |
| 1640 | 830 | 630 |
| 1160 | 580 | 430 |
|
| 1500 | 780 | 640 |
| 1030 | 540 | 440 |
-1.5 | *2370 | 1480 |
| 810 | *2370 | 1010 |
| 560 |
